Obtain increased wheel travel with a mild lift height with this heavy duty Upper Control Arm systems. The tubular Upper Control Arms feature 1.25in OD, .120in wall thick chromoly tube construction with 1in diameter Stainless Steel Uniballs that attach to the factory spindle without drilling. The replacement UCA's have been designed to work in conjunction with Fabtech's Dirt Logic 2.5 Coilover shocks providing 10in of wheel travel for a complete front suspension system upgrade. The vehicle's offroad suspension performance will be greatly increased due to the extensive ride tuning of the Dirt Logic 2.5 Coilovers and rear Dirt Logic 2.25's. Features & Benefits: Arms eliminate upper ball joint w/ super strong 1in ID Stainless American Uniball. Additional caster is built into Arms for greater align ability to help with problematic leveling kit alignments. Allows for increased wheel travel when used with Dirt Logic 2.5 Coilover shocks. Chromoly tubing reduces flex found in stock arms for more positive road feel. 17-4 Stainless Steel Heat treated Uniball pin fits into factory ball joint taper without modification to the spindle for easy return to stock feature. Arms are direct replacements for factory arms on suspensions that require additional strength and align ability. Material Construction Specs: Built with same materials as found on Trophy Trucks. .120in Wall 4130 Chromoly Tubing. 1.25in OD. .250in wall DOM Bushing Barrels. 1in ID Stainless Steel American Uniball. 17-4 Stainless Misalignments. Heat Treated 17-4 Stainless Steel Tapered Uniball Pins.

Specifications:

California Proposition 65	WARNING: Cancer & Reproductive Harm and image
Title	Fabtech 3" UCA & DLSS 2.5 C/O SYS W/ DLSS RESI RR SHKS 15-21 TOYOTA TACOMA 2WD/4WD 6 LUG
Description_ASC	TIRE SIZE - 33/12.50R17 WHEEL - 17X8 W/4 5/8" BS W/MINOR TRIMMING; TIRE SIZE - 275/70R18 WHEEL - 18X9 W/4 3/4" BS W/MINOR TRIMMING; TIRE SIZE - 275/60R20 WHEEL - 20X9 W/5" BS W/MINOR TRIMMING
Description_DEF	Suspension Lift Kit
Description_DES	3" UCA & DLSS 2.5 C/O SYS W/ DLSS RESI RR SHKS 15-21 TOYOTA TACOMA 2WD/4WD 6 LUG
Description_EXT	3" UCA & DLSS 2.5 C/O SYS W/ DLSS RESI RR SHKS 15-21 TOYOTA TACOMA 2WD/4WD 6 LUG MODELS.
Description_INV	Fabtech-3" UCA & DLSS 2.5 C/
Description_MKT	Obtain increased wheel travel with a mild lift height with this heavy duty Upper Control Arm systems. The tubular Upper Control Arms feature 1.25in OD, .120in wall thick chromoly tube construction with 1in diameter Stainless Steel Uniballs that attach to the factory spindle without drilling. The replacement UCA's have been designed to work in conjunction with Fabtech's Dirt Logic 2.5 Coilover shocks providing 10in of wheel travel for a complete front suspension system upgrade. The vehicle's offroad suspension performance will be greatly increased due to the extensive ride tuning of the Dirt Logic 2.5 Coilovers and rear Dirt Logic 2.25's. Features & Benefits: Arms eliminate upper ball joint w/ super strong 1in ID Stainless American Uniball. Additional caster is built into Arms for greater align ability to help with problematic leveling kit alignments. Allows for increased wheel travel when used with Dirt Logic 2.5 Coilover shocks. Chromoly tubing reduces flex found in stock arms for more positive road feel. 17-4 Stainless Steel Heat treated Uniball pin fits into factory ball joint taper without modification to the spindle for easy return to stock feature. Arms are direct replacements for factory arms on suspensions that require additional strength and align ability. Material Construction Specs: Built with same materials as found on Trophy Trucks. .120in Wall 4130 Chromoly Tubing. 1.25in OD. .250in wall DOM Bushing Barrels. 1in ID Stainless Steel American Uniball. 17-4 Stainless Misalignments. Heat Treated 17-4 Stainless Steel Tapered Uniball Pins.
Description_SHO	3" UCA & DLSS 2.5 C/

This Part Fits:

Year	Make	Model	Submodel	Notes
2022	Toyota	4Runner	Limited
2022	Toyota	4Runner	Nightshade
2022	Toyota	4Runner	SR5
2022	Toyota	4Runner	SR5 Premium
2022	Toyota	4Runner	Trail
2022	Toyota	4Runner	TRD Off-Road
2022	Toyota	4Runner	TRD Sport
2022	Toyota	4Runner	Venture
2015	Toyota	Tacoma	Base	6 LUG
2016	Toyota	Tacoma	Limited	6 LUG
2017	Toyota	Tacoma	Limited	6 LUG
2018	Toyota	Tacoma	Limited	6 LUG
2019	Toyota	Tacoma	Limited	6 LUG
2020	Toyota	Tacoma	Limited	6 LUG
2021	Toyota	Tacoma	Limited	6 LUG
2021	Toyota	Tacoma	Nightshade
2017	Toyota	Tacoma	Sport
2018	Toyota	Tacoma	Sport
2019	Toyota	Tacoma	Sport
2016	Toyota	Tacoma	SR	6 LUG
2017	Toyota	Tacoma	SR	6 LUG
2018	Toyota	Tacoma	SR	6 LUG
2019	Toyota	Tacoma	SR	6 LUG
2020	Toyota	Tacoma	SR	6 LUG
2021	Toyota	Tacoma	SR	6 LUG
2016	Toyota	Tacoma	SR5	6 LUG
2017	Toyota	Tacoma	SR5	6 LUG
2018	Toyota	Tacoma	SR5	6 LUG
2019	Toyota	Tacoma	SR5	6 LUG
2020	Toyota	Tacoma	SR5	6 LUG
2021	Toyota	Tacoma	SR5	6 LUG
2021	Toyota	Tacoma	Trail
